SD8524H
FAST TURN-OFF SYNCHRONOUS RECTIFIER CONTROLLER

    SD8524H is a high-performance, fast turn-off synchronous rectifier controller with a built-in 100V MOSFET. It replaces diode rectifiers for high efficiency in high-performance isolated power supply topology application. It can work with the flyback controller in CCM, DCM, QR modes.

    SD8524H can be powered by the high-voltage winding or the output voltage in the flyback converter applications. A slew rate detection circuit prevents the SD8524H from turning on falsely during resonance operation.

    The SD8524H is available in SOP8 package.


Main feature

  • Integrated high-performance MOSFET (100V, 15mΩ)

  • Supports both high-side and low-side synchronous rectification applications

  • Supports DCM, CCM, and QR operations

  • Slew rate detection prevents false turn-on during resonance operation

  • Powered by the high-voltage winding or the output voltage

  • 250μA standby current

  • SOP8 package


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD8524H SOP-8-225-1.27 SD8524H Halogen free Tube
SD8524HTR SOP-8-225-1.27 SD8524H Halogen free Tape & Reel
Block Diagram

SD8524H 英文 （4500&1725）.png
